Mean Well HRP and HRPG Chassis Mount Power Supply

Mean Well HRP Range - Slim Enclosed Power Supplies

HRP Series: Compact, diverse range of enclosed power supplies
Input: Universal AC input/Full range
Energy Efficiency: Built-in active PFC function, PF>0.95, with high efficiency up to 89%
Surge Protection: Withstands 300VAC surge input for 5 seconds
Protections: Short circuit, Overload, Over voltage, Over temperature
Cooling: Cooling by free air convection
Additional Features: Built-in constant current limiting circuit and remote sense function
Profile: 1U low profile of 38mm

HRP-75 Series:

HRP-75-3.3 - 3.3Vdc 15A
HRP-75-5 - 5Vdc 15A
HRP-75-7.5 - 5Vdc 19A
HRP-75-12 - 12Vdc 6.3A
HRP-75-15 - 15Vdc 5A
HRP-75-24 - 24Vdc 3.2A
HRP-75-36 - 36Vdc 2.1A
HRP-75-48 - 48Vdc 1.6A

HRP-100 Series:

HRP-100-3.3 - 3.3Vdc 20A
HRP-100-5 - 5Vdc 17A
HRP-100-7.5 - 7.5Vdc 13.5A
HRP-100-12 - 12Vdc 8.5A
HRP-100-15 - 15Vdc 7A
HRP-100-24 - 24Vdc 4.5A
HRP-100-36 - 36Vdc 2.9A
HRP-100-48 - 48Vdc 2.2A

HRP-150 Series:

HRP-150-3.3 - 3.3Vdc 30A
HRP-150-5 - 5Vdc 26A
HRP-150-7.5 - 7.5Vdc 20A
HRP-150-12 - 12Vdc 13A
HRP-150-15 - 15Vdc 10A
HRP-150-24 - 24Vdc 6.5A
HRP-150-36 - 36Vdc 4.3A
HRP-150-48 - 48Vdc 3.3A

HRPG-150 Series:

HRP-200 Series:

HRP-200-3.3 - 3.3Vdc 40A
HRP-200-5 - 5Vdc 35A
HRP-200-7.5 - 7.5Vdc 26.7A
HRP-200-12 - 12Vdc 16.7A
HRP-200-15 - 15Vdc 13.4A
HRP-200-24 - 24Vdc 8.4A
HRP-200-36 - 36Vdc 5.7A
HRP-200-48 - 48Vdc 4.3A

HRPG-200 Series:

HRP-300 Series:

HRP-300-3.3 - 3.3Vdc 60A
HRP-300-5 - 5Vdc 60A
HRP-300-7.5 - 7.5Vdc 40A
HRP-300-12 - 12Vdc 27A
HRP-300-15 - 15Vdc 22A
HRP-300-24 - 24Vdc 14A
HRP-300-36 - 36Vdc 9A
HRP-300-48 - 48Vdc 7A

HRPG-300 Series:

HRP-450 Series:

HRP-450-3.3 - 3.3Vdc 90A
HRP-450-5 - 5Vdc 90A
HRP-450-7.5 - 7.5Vdc 60A
HRP-450-12 - 12Vdc 37.5A
HRP-450-15 - 15Vdc 30A
HRP-450-24 - 24Vdc 18.8A
HRP-450-36 - 36Vdc 12.5A
HRP-450-48 - 48Vdc 9.5A

HRPG-450 Series:

HRP-600 Series:

HRP-600-3.3 - 3.3Vdc 120A
HRP-600-5 - 5Vdc 120A
HRP-600-7.5 - 7.5Vdc 80A
HRP-600-12 - 12Vdc 53A
HRP-600-15 - 15Vdc 43A
HRP-600-24 - 24Vdc 27A
HRP-600-36 - 36Vdc 17.5A
HRP-600-48 - 48Vdc 13A
